Features & Benefits

  • Excellent anti-vibration mechanical design and thermal solution
  • EMCU provides audible alarm and LED function
  • High-efficiency 420w (1+1) redundant power supply
  • Support 6Gb/s SAS/SATA
  • Fully utilized space to support 16 x 3.5" hot-swap HDD
Form Factor (H) x (W) x (D)2RU 16-Bay, 19" Rackmount Chassis
3.47" x 17.2" x 26.38"
88.1 mm x 437 mm x 670 mm
I/O ControllerSingle 6Gb/s SAS 2.0
Host InterfaceOne 6Gb/s SAS 4x Wide Ports via SFF-8088
Expansion InterfaceUp to two 6Gb/s SAS 4x wide port via SFF-8088
Drive Bay16x 3.5" Hot Swappable Drive Caddy
Support 6Gb/s & 3Gb/s SAS and SATA Drive
Control Panel1x System Power Button
1x Alarm Release Button
Indicator1x Power Status LED
1x Overheat LED
1x Fan Failed LED
1x HDD Status LED per HDD
1x HDD Failed LED per HDD
1x Fan Operated LED per Fan Module
1x Fan Failed LED per Fan Module
Fan Module4x 80 mm Hot Swappable Fan Modules
Electrical RequirementHigh-efficiency 420w (1+1) Redundant Power Supply
W/ PFC, AC 90~264V Full Range, 47Hz~63Hz
Monitor and AlarmOverheat Monitoring and Warning
System Fan Module Status Monitoring and Warning
Power Supply Unit Status Monitoring and Warning
HDD Status Monitoring and Warning
EnvironmentalOperating: 10˚C~35˚C (50˚F~94.9˚F)
Non-operating: -40˚C~70˚C (-40˚F~158˚F), 5% ~85% Non-condensing
Part NameOrder CodeDescriptionMSRP (USD)Gallery
27" Ball Bearing SlideSLR-DS-2701 27", Ball BearingCall
3.5" Hard Drive CaddyHDC35-002-BL3.5", BlueCall
3.5" Hard Drive CaddyHDC35-002-BR3.5", BrownCall
3.5" Hard Drive CaddyHDC35-001-BL3.5", BlueCall
3.5" Hard Drive CaddyHDC35-001-BR3.5", BrownCall
3.5" Front CoverHDC35-901-GR3.5", GreenCall
8038 Fan ModuleFMA-8038-SU80 x 80 x 38 mmCall
External SAS CableCBOT-0001SFF-8088 to SFF-8088, 1.8mCall
External SAS CableCBOT-0002SFF-8088 to SFF-8088, 1.0 mCall
2.5 inch HDD ConverterHD-CVR-036Gb/s, SAS/SATA/SSDCall
DescriptionVersionSizeUpload DateDownload Link
Data Sheet1.0309KB2013-12-11
